Ship From Spain Stock 26" 27.5" 29" 48V 1000W 1500W Electric Bike Conversion Kit With 48V 18A lithium Battery

SKU

EU48VMTX

Be the first to review this product

In stock

$269.00

Included

Volatage and Power

Rim Size

Dropout Type

Ship to below countries only

Qty

Add to Wish List Add to Compare

Overview

Ship From Spain Stock 26" 27.5" 29" 48V 1000W 1500W Electric Bike Conversion Kit With 48V 18A lithium Battery

Details

Ship From Spain Stock 26" 27.5" 29" 48V 1000W 1500W Electric Bike Conversion Kit With 48V 18A lithium Battery

Packing List

1* Front or Rear motor wheel

1 * DC Controller

1 * Controller Bag

1 Pair * Power cut-off Brake lever

1 * SW900 Display

1 * 8 Magnet Pedal Assistant Sensor

1 * Twist Throttle

1 * 160mm disc brake

1 * 7 speed thread freewheel

1 * Outside tire+ inner tire

Product Details

1. Motor wheel

1).48V motor wheel

a. Full No-load Speed:

48V 1000W about 45-55km/h

48V 1500W about 50-60km/h

b. Rim: Double-wall Aluminium Alloy Rim /25mm inner width

c. Hub Motor: 48V Brushless Non-gear Hub Motor

d.Rear wheel Bottom bracket: 135mm-142mm

e.Rotating speed

48V 500W/1000W:470RMP

48V 1500W:540RMP

f.torque

48V 1000W: 30-40NM

48V 1500W: 35-45NM

1. This is Rear Moter wheel, it suitable the frame of your bike with dropout in 135mm-142mm, please measure your frame as picture below:

2. Controller

CSC 12 mosfet controller
Fit for: 48V 1000W motor wheel，SW900 Display
Rated current: 22A , Max current: 44±1A
Size: 149*83.3*42mm

CSC 15 mosfet controller
Fit for: 48V 1500W motor wheel ，SW900 Display
Rated current: 35A , Max current: 70±1A
Size: 118.2*82.33*41mm

1). Controller Bag or box,

It may be different in look, if you mind it, please contact us before you buy it.

2. SW900 Display

Functions

2.1 LCD Display

Speed indicator, PAS grades indicator, Battery indicator, Error indicator, Single Trip Distance and

Total Distance, Headlight indicator.

2.2 Parameters Setting

Power on/off, Headlight on/off, 6KM/H Cruise control, Wheel size, Max speed setting,

Auto stand-by and sleep mode setting, Background luminance setting, Working voltage setting

3. PAS sensor- 8 Magnet

5. Brake Lever

6. Throttles

Twist Throttle

Factory and Warehouse
